Shyamo Engineers brings you cranes designed for top performance and reliability. Our Single Girder Cranes are built to improve your material handling tasks, offering strong lifting power and flexibility. Whether you’re in manufacturing, construction, or any industry that needs precise lifting and moving, our cranes are made to suit your needs perfectly.
Benefits Of Single Girder Cranes?
- Optimal Load Capacity: Our single-girder cranes come in a variety of load capacities, ensuring you get the perfect fit for your specific needs. Whether you need a light-duty crane or a heavy-duty solution, our cranes can handle loads ranging from ½ tons to 25 tons with ease.
- Space-Saving Design: Designed for efficiency, Single Girder Cranes take up less space than double girder cranes. With their higher headroom and compact footprint, our specially designed models are perfect for facilities with limited overhead space.
- Cost-Effective Solution: Single girder cranes are a more economical choice compared to double girder cranes. Their lighter weight reduces the need for large foundations, gantry girders, and pillars, significantly cutting down the overall building cost.
- Lower Freight Costs:Since single-girder cranes are lighter, freight costs are also reduced, making transportation more affordable.
- Faster Deliveries:We understand the importance of time in your operations. That’s why Shyamo Engineers’ Single Girder Cranes are designed for quicker delivery, getting you up and running faster.
What is a Single Girder Overhead Crane?
A single girder overhead crane is a material handling system comprising one horizontal bridge girder supported at both ends by end trucks that run on elevated runway rails. The electric wire rope hoist or chain hoist trolley travels along the bottom flange of this girder, enabling precise three-dimensional load movement throughout the workspace.
The overhead crane single girder design is the most widely adopted configuration in Indian industries, offering an ideal balance between structural economy and lifting performance. By utilising the underside of the girder as the trolley track, the design maximises available hook height within a given building clearance.
Single girder overhead cranes are manufactured to IS 3177 and FEM standards and are available in top-running and under-slung (under-hung) configurations, making them suitable for a broad spectrum of light-to-medium duty industrial applications where capacities up to 20 tonnes and spans up to 28 metres are required.
Key Features of Single Girder Overhead Cranes
Every single girder overhead crane we manufacture is built to deliver reliable performance, extended service life, and minimal maintenance demands.
Robust Box-Section Girder
Welded box-section or I-beam girder construction fabricated from IS 2062 structural steel, offering excellent stiffness-to-weight ratio with camber pre-set for long-span deflection control.
Precision Hoist Unit
Wire rope or chain hoist with helical gearbox, flame-proof or weatherproof motor options, and Class H insulation for continuous-duty reliability across harsh Indian industrial environments.
Variable Frequency Drive
Optional VFD on all motions enables smooth acceleration/deceleration, micro-speed positioning, and significant energy savings compared to conventional contactor-controlled drives.
Advanced Safety Systems
Overload protection relay, dual-circuit limit switches for upper and lower travel limits, anti-collision proximity sensors, and emergency stop integrated as standard across all models.
Smart Control Pendant
Ergonomic cable pendant with IP55 protection, clearly labelled push buttons, emergency stop mushroom head, and optional radio remote control for operator safety and flexibility.
Low Maintenance Design
Sealed-for-life end truck wheel bearings, centralised lubrication access points, and hot-dip galvanised or epoxy-coated runway components significantly reduce planned maintenance downtime.
Built to Your Needs: Available Customisation Options
- Speeds range from 0.5 mpm to 15 mpm.
- Single girder cranes are available with spans up to 30 meters, in single or split-length configurations.
- Lifting capacity ranges from 3 meters to 90 meters.
No two facilities are the same. We work with your engineers and plant managers to configure each single girder overhead crane precisely for your environment, process, and budget.
Structural Options
Mechanical Options
Controls & Automation
Types of Single Girder
Overhead Cranes
- Standard Single Girder Cranes – Ideal for various industrial applications.
- Underslung/Underhung Cranes – Designed for efficient space utilization and smooth movement.
- Single Girder Crane with Overhanging Trolley – Offers extended reach for better load handling.
- We manufacture four primary configurations of single girder overhead cranes — each suited to different mounting conditions, headroom constraints, and operational environments.
| Type | Mounting | Span | Capacity | Best For | Standard |
|---|---|---|---|---|---|
| Top Running Single Girder | Runs on top of runway rail | Up to 30 m | 1 – 20 t | New construction, maximum hook height | IS 3177 |
| Under-slung / Under-hung | Hangs from bottom flange of runway beam | Up to 12 m | 0.5 – 5 t | Low headroom, retrofits, no floor columns | FEM 1.001 |
| Freestanding Gantry Crane | Self-supporting A-frame structure | Up to 20 m | 1 – 10 t | No building structure available, outdoor use | IS 807 |
| Semi-Gantry Crane | One side on runway, other on floor legs | Up to 25 m | 1 – 16 t | Asymmetric bays, mixed indoor/outdoor spans | IS 3177 |
- Crane Maintenance Manual: Download the Maintenance Manual for Shyamo Engineers EOT Crane for free. This guide provides step-by-step instructions for maintaining your crane, ensuring smooth operation and longevity.
- . Understanding Single Girder Crane Nomenclature: Learn the different parts and terminology of a Single Girder Crane to better understand its design, functionality, and usage
- Crane Enquiry Form: Easily access and download the Electric Overhead Double Girder, Single Girder, Gantry, and Goliath Crane Enquiry Form. Fill it out to request a quote or get more details about the crane that best suits your needs.
Frequently Asked Questions
Have a question about single girder overhead cranes? We have answered the most common ones below.
